Paragon Kiln - Darby Dipper
|Model:||Paragon Darby Dipper|
|Dimensions Inside:||7.5" (length) x 7.5" (width) x 9" (depth)|
|Elements:||Top Elements Only|
|Max Temp:||Fires to 2350° F|
|Shipping Weight:||95# (UPS)|
- FREE SHIPPING in the contiguous US!
- 3-Key Digital Sentry Xpress Controller
- On/Off Safety Switch
- S-Type platinum thermocouple with ceramic protection
- Built-in Stand
- Instruction Manual
- 1-year Limited Warranty
The Darby Dipper glass blower’s kiln will give you the freedom to enjoy crucible firing in a small space, mix your own custom glass colors, make paperweights, blown vessels, stringers, and much more... Imagine pulling your own neon tubing in this affordable kiln. This crucible furnace is designed for glass blowers who need a small, 240 volt kiln for making custom glass colors, blown vessels, and neon tubing. The 7 1/2” square x 9” deep Darby Dipper can also be ordered in 240 volts and for electrical systems overseas.
The Darby Dipper is well insulated for the long firings typical of crucible work. The walls, top, and bottom are made of 3” high temperature K-25 firebricks which are 20% thicker than standard 2 1/2” firebricks and designed for prolonged high temperature holds. For extra insulation, the walls are wrapped with a ceramic fiber blanket, which is behind the stainless steel case. With the extra insulation and heavy-duty elements, the Darby Dipper is reliable even during very long heat soaks. For easy maintenance, tighten the stainless steel top band and kiln case with the case adjustment screws. Access to the crucible is gained through a 6” hole in the kiln top.
The kiln includes a firebrick cover with handle to place over the 6” hole. Sidewall heating elements are protected in dropped, recessed firebrick grooves. The stainless steel case can be adjusted with case tighteners. The Darby Dipper includes the Sentry Xpress digital controller. Because of the extended holds at high temperatures, the controller is in a separate wall-mounted panel. This keeps the controller away from the heat for longer life. The control panel is attached to the kiln with 6’ cables. A pilot light glows when the elements turn on.
The kiln comes with a one-year warranty. (Please note: Due to the long firing cycles of a crucible kiln, the warranty does not cover the heating elements.) The built-in stand comes with mar-proof plastic feet and provides the firebrick bottom with a full layer of sheet metal support.
