AmeriBrade - Kamimura Trident 2x48 Belt Grinder

Sale price$ 1,135.00
Buy Now, Pay Later
withBread Pay Logo

Payment & Security

American Express Apple Pay Diners Club Discover Google Pay Mastercard PayPal Shop Pay Venmo Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.


This Kamimura Package Includes:

  • FREE SHIPPING in the contiguous US!
  • Pre-Wired, Totally Enclosed Fan Cooled Motor (Variable Speed or Single Speed Options)
  • Fully Assembled and Powder Coated Steel Frame
  • Small Wheel Holder That Accepts a Wide Range of Small Wheel Sizes (.375” thru 1.75”) located above the platen
  • 1” Diameter Small Wheel (other sizes ordered separately)
  • 2” Wide x 8” Tall Case Hardened Platen
  • 4” Diameter x 2” Wide Rubber Contact Wheel (Durometer: 65A ) located below the platen
  • Removeable Platen for Slack Grinding
  • Adjustable Work Rest (Tilt Range -14 degrees to +45 degrees)
  • Easy-Release Ratcheting Tension for Fast Belt Changes
  • Spark Shields
  • Stable and Adjustable Belt Tracking
  • Instruction Manual
  • Lifetime Warranty - Grinder Frame/Components
  • 2-Year Limited Warranty - Motors, Controllers, Wheels and Bearings (Refer to Manufacturer's Warranty)

Does Not Include Pedestal Stand, but it is compatible with this pedestal stand if you prefer that over mounting it to your bench.

In pursuit to offer products that improve the crafstman’s shop experience, AmeriBrade felt there was a missing option for anyone that doesn’t want the added price associated with their more complex 2x72 machine, but still needs a higher quality option than a frustrating beginner machine. This 2x48 offers all of the most essential grinding accessories in a single configuration that is simple to use and has a small footprint. Neil Kamimura is partnering with AmeriBrade to develop this grinder because he shares in their vision of making a high quality machine that is more accessible to a wider range of makers.

Add a Belt Kit with your AmeriBrade Grinder!

2x48 RPM Neil Kit (17 Belts):

  • 36 Grit Shredder Ceramic -X weight (2 pieces)
  • 60 Grit Shredder Ceramic -X weight (2 pieces)
  • 80 Grit Shredder Ceramic -X weight (2 pieces)
  • 120 Grit Shredder Ceramic -X weight (2 pieces)
  • 220 Grit Shredder Ceramic -J Flex (2 pieces)
  • 120 Grit -J Flex (1 piece)
  • 320 Grit - J Flex (1 piece)
  • 400 Grit - J Flex (1 piece)
  • Medium Surface Conditioning ( 1 piece)
  • 36 Grit Aluminum Oxide - X Weight (1 piece)
  • 220 Grit Aluminum Oxide - X Weight (1 piece)
  • 400 Grit Aluminum Oxide - X Weight (1 piece)

Do Not Run Variable Speed Units on circuits containing a GFCI.

Click here to download and read about the 2x48 Grinder Instruction Manual.
